Metal forging is one of the oldest and most reliable manufacturing processes, renowned for producing parts with excellent mechanical properties, such as high impact strength and fatigue resistance. However, this process also faces many significant challenges.

The following are the main challenges of metal forging, categorized by their impact on the manufacturing process:

1. Material-Related Challenges

1) Inconsistent Material Flowability: Different metals have varying degrees of ductility. Low-ductility materials are prone to cracking, tearing, or internal fracture during deformation. Carbide requires higher forming forces and is more difficult to machine into complex geometries.

2) Temperature Sensitivity: Inappropriate forging temperatures can lead to defects. Too low a temperature can result in insufficient plasticity and cracking; too high a temperature can lead to overheating, scorching, and coarse grains, thus reducing mechanical properties.

3) Microstructure Inhomogeneity: Uneven deformation can lead to inconsistent grain sizes in the workpiece, resulting in uneven hardness and strength.

2. Process and Technical Challenges

1) High Forming Force Requirements: Forging requires large presses or forging hammers. 1) Manufacturing large or complex parts requires energy-intensive, heavy-duty equipment.

2) Die wear and failure: Repeated impacts, high temperatures, and friction can cause die wear, thermal fatigue, and cracking. The manufacturing and replacement costs of dies are high, thus increasing production costs.

3) Dimensional accuracy control: Springback after forging alters part dimensions. Thermal shrinkage and die deformation also make it difficult to obtain high-precision parts. Secondary machining is often required.

4) Limitations of complex parts: Complex hollow, thin-walled, or deep-profile parts are difficult to forge. Material cannot completely fill narrow die cavities, leading to incomplete filling defects.

3. Defect Control Challenges

1) Common forging defects include: cracks, folds, laminations, incomplete filling, residual stress, and internal voids.

2) Residual stress can cause parts to warp or deform after cooling or during use. Inspecting internal defects beneath the surface increases the inspection workload.

4. Production and Economic Challenges

1) High Costs: Expensive forging equipment, custom molds, high energy consumption, and the need for skilled operators all increase overall production costs. Forging is less economical for small batches of simple parts.

2) Limited Production Efficiency: Forging typically requires multiple heating, pre-forming, and finishing processes. Compared to casting or stamping, forging has a longer cycle time.

3) Environmental Issues: High-temperature heating consumes a large amount of energy. Oxide scale generated during hot forging produces waste, and forging equipment generates significant noise and vibration.

5. Post-Processing Challenges

1) Oxide scale is present on the surface of hot-forged parts, requiring cleaning. Heat treatment is crucial for optimizing grain structure and eliminating residual stress, but this adds additional processing steps.
